Three-phase Rectifier Module N0/N1 Product
Three-phase Rectifier Module N0/N1 Product Back
 PDF

Introduction 1、The modules introduced this time mainly contain:N0 (36.6mm*34.6mm*12mm) / N1 (68.4mm*32.5mm*20.7mm) series package;
2、VRRM ≥1800V ，ID= 35A~60A；
3、Mainly used for three-phase rectification;
4、The modules and other market mainstream products are completely pin to pin alternatives;
5、The modules use environmentally friendly materials and comply with RoHS standards;
Features 1、Tjmax=150℃;
2、Three-phase bridge rectifier；
3、Blocking voltage: 1800V；
4、Heat transfer through DBC ceramic isolated metal baseplate；
5、Glass passivated chip；
SPECIFICATION

MD35S18N0 MD40S18N1 MD60S18N1
